Bitumen Testing Instruments

Bitumen Testing Instruments - Bitumen - Asphalt Testing Equipment, Ring And Balll Apparatus, Standard Penetrometer, Ductility Testing Apparatus, Stripping Value Apparatus, Benkleman Beam, Centrifuge Extractor, Marshall Stability Test Apparatus

Ring & Ball Apparatus For Testing Lab for Bitumen Testing Lab

NBTE-M1

Ring & Ball Apparatus for Bitumen Testing - This apparatus is used to determine Softening point of Bitumen. It is that temperature at which a sample of bituminous material loaded by a 9.5mm dia steel ball, drops a specified distance when heated under specified conditions. The apparatus consists of steel bracket with a sliding plate support. That support has two holes of 10mm dia on which a rin....

Water in Bituminous Material (DEAN-STARK) For Testing Lab for Bitumen Testing Lab

NBTE-M2

Water in Bituminous Material (DEAN-STARK) for Bitumen Testing - Used to determine the water in petroleum products or bituminous materials by distilling them with volatile solvent. The equipment comprises electric heater with thermoregulator, glass still, support stand, condenser, receiving trap, clamp.

Ring & Ball Apparatus (Electrical) For Testing Lab for Bitumen Testing Lab

NBTE-M3

Ring & Ball Apparatus (Electrical) for Bitumen Testing - Electrical heating, with a Heater and Energy Regulator, Suitable for operation on 230 V, 50Hz, Single Phase, A.C. supply. Each unit is supplied with bath of heat resistant glass and the following. - Tapered Rings, 2 Nos. - Ball Centering Guide, 2 Nos. - Steel Ball, of 9.5mm dia, 2 Nos. - Ring Holder, 1 No. - Electric Heater (Hot Pla....

Standard Penetrometer For Testing Lab for Bitumen Testing Lab

NBTE-M4

Standard Penetrometer for Bitumen Testing - Used to determine grade of bitumen. The penetration tests determine consistency of bitumen for the purpose of grading. Depth in units 1/10 of millimeter to which a standard needle having a standard weight will penetrate vertically in a duration of five seconds at a temperature of 25�C determines penetration for gradation. It consists of a vertical....

Semi-Automatic Penetrometer For Testing Lab for Bitumen Testing Lab

NBTE-M5

Semi-Automatic Penetrometer for Bitumen Testing - Used to determine grade of bitumen. The penetration tests determine consistency of bitumen for the purpose of grading. Depth in units 1/10 of millimeter to which a standard needle having a standard weight will penetrate vertically in a duration of five seconds at a temperature of 25�C determines penetration for gradation. Compact with timer....

Straight Edge (3 Meters) For Testing Lab for Bitumen Testing Lab

NBTE-M6

Straight Edge (3 Meters) for Bitumen Testing - A straight edge approximately 3 metres in length may be used to determine lateral surface regularity of a road surface. This lightweight apparatus is made up of mild steel or aluminum as per customers requirement and is equally supported at both ends producing a set height between the road surface & the beam. Any vertical irregularity is measured ....

Reflux Extractor 4000 GMS For Testing Lab for Bitumen Testing Lab

NBTE-M7

Reflux Extractor 4000 GMS for Bitumen Testing - The simple apparatus working on the same operation principle of consisting of cylindrical glass jar supporting two metal cones of stainless steel cloth and a metal condenser on top of the jar. Supplied complete with 100 filter papers & wire gauge, Hot Plate. Spare Cylindrical glass jar can be supplied at an extra cost.

Hardness Tester for Mastic Asphalt For Testing Lab for Bitumen Testing Lab

NBTE-M8

Hardness Tester for Mastic Asphalt for Bitumen Testing - For determining the hardness number of Mastic Asphalt for flooring. It consist of an internally insulated cabinet to the base of which is fitted a water bath having two taps. The bath is heated by an immersion heater and the temperature is controlled with the thermostat at 35� +/- 0.5� C. A 6.5mm dia pin is loaded on the specim....

Stripping Value Apparatus For Testing Lab for Bitumen Testing Lab

NBTE-M9

Stripping Value Apparatus for Bitumen Testing - For determining stripping value of bituminous mixes having aggregate size: 1.0mm to 75 micron. A circular tray rotates in a vertical plane at a rate of approximately 100 R.P.M. by an electrical geared motor. 4 bottles of approximately 400 cc are mounted 0 on this circular tray at an angle of 90 . To each other with their mouth towards center of the t....

Binder Extractor (Hand Operated) For Testing Lab for Bitumen Testing Lab

NBTE-M10

Binder Extractor (Hand Operated for Bitumen Testing - The Instrument is used for determination and checking of Bitumen percentage in Bituminous mix, the mix is added with a solvent and dissolved bitumen is removed by centrifugal action. Consists of a removable Aluminum rotor bowl, Capacity 1500 gms. With a cap and tightening nut. The bowl assembly is mounted on a vertical shaft, which protrudes fr....

Centrifuge Extractor (Motorised) For Testing Lab for Bitumen Testing Lab

NBTE-M11

Centrifuge Extractor (Motorised) for Bitumen Testing - Centrifuge Extractor, Electrical Operation, Capacity 1500g, with a Dimmer stat for speed control from 2,400 to 3,600 rpm. Suitable for operation on 230 V, 50 Hz, Single Phase, A.C. supply.

Centrifuge Extractor (Motorised) For Testing Lab for Bitumen Testing Lab

NBTE-M11A

Centrifuge Extractor (Motorised) for Bitumen Testing - Used for the determination of bitumen percentage in bituminous mixtures. It consists of a removable, precision machined aluminium rotor bowl (accessory 1500 or 3000 g capacity), housed in a cylindrical aluminium box. The separate control panel incorporates an electronic card fitted with AC drive that automatically drives the bowl speed rotatio....

SAY Bolt Viscometer For Testing Lab for Bitumen Testing Lab

NBTE-M12

Say bolt Viscometer, Electrically Heated, ASTM D88, D244, AASHTO T72 for Bitumen Testing - for the empirical measurement of Say bolt Viscosity of petroleum products at specified temperatures between 70o F and 210o F. This is also used for determining the Saybolt Furol Viscosity of bituminous materials at temperatures of 250, 275, 300, 350, 400 and 450 F. It comprises one each of cylindrical Oil cu....

Standard TAR Viscometer For Testing Lab for Bitumen Testing Lab

NBTE-M13

Standard TAR Viscometer for Bitumen Testing - Electrical Heating with Immersion Heating Elements and Dimmer stat for controlling the temperature. Suitable for operation on 230 V, 50Hz, Single Phase , A.C. supply Complete with 10mm cup and Ball Valve, 10mm

Manual Compaction For Testing Lab for Bitumen Testing Lab

NBTE-M14

Manual Compaction for Bitumen Testing - Comprising Mould body, base plate and combined filling / extraction collar.

Mixer with Heating Jacket For Testing Lab for Bitumen Testing Lab

NBTE-M15

Mixer with Heating Jacket for Bitumen Testing - A 6-litre Mixer Used in conjunction with an Iso Mantle, is suitable for mixing samples of asphalt. Bench mounting Mixer, 6 liter nominal capacity. Supplied with bowl, beater and whisk. Motorised with two speed operated on 230 V A.C., Single Phase. ISO MANTLE ELECTRIC HEATER - For use of Bench Mounting mixer. For 230 V A.C. , 50Hz, Single Phase

Marshall Stability Test Apparatus For Testing Lab for Bitumen Testing Lab

NBTE-M16

Marshall Stability Test Apparatus for Bitumen Testing -
- It consists of body housing, a geared screw jack and motor drive mechanism suitable for operation on 230 V, 50Hz, Single Phase, A.C. supply. Robust Construction 50KN capacity, Rate of travel 50.8mm/min, Safety cut-off switch. - MARSHAL LOAD FRAME 1No. - Breaking Head Stability Mould, with a dial gauge ( having 25mm travel and 0.0....

Digital Marshall Stability Test Apparatus For Testing Lab for Bitumen Testing Lab

NBTE-M16A

Digital Marshall Stability Test Apparatus for Bitumen Testing - This versatile digital loading frame features a microprocessor controlled drive system with stepper motor enabling the operator to easily set any test speed by digital switches. The machine is fitted with an RS 232 C port so it can be remotely controlled by a personal computer. The upper and lower limits of platen travel are set by us....

Pavement Core Drilling Machine For Testing Lab for Bitumen Testing Lab

NBTE-M17

The Pavement Core Drilling Machine for Bitumen Testing - Diesel engine powered road building drill has been designed specifically for the purpose of drilling test cores from or holes in, Roads, Airport Runways, Bridges etc. The Machine comprises of two vertical support columns, which carry the Drill head/Engine assembly with the help of screwed spindle. The 5 HP diesel engine with pulley mechanism....

Automatic Compactor For Testing Lab for Bitumen Testing Lab

NBTE-M18

Automatic Compactor for Bitumen Testing - Automatic Compactor for Bituminous Mixes: Rugged construction to withstand hard work, Fully automatic and easy to operate Uniform compaction, Automatic Preset Blow Counter Specification : The Automatic Compactor eliminates the laborious process of manual compaction and an even degree of compaction is achieved. The driven mechanism lifts the weight of 4.....

Ductility Testing Apparatus For Testing Lab for Bitumen Testing Lab

NBTE-M19

Ductility Testing Apparatus for Bitumen Testing - Designed to test three specimens simultaneously. The machine consists of a carriage moving over a lead screw. An electric motor driven reduction gear unit ensures smooth constant speed and continuous operation. The entire assembly is mounted with a stainless steel lined water bath completely encased in metal bound hardwood. It is equipped with an e....

BENKELMAN Beam: Lightweight Aluminium construction For Testing Lab for Bitumen Testing Lab

NBTE-M20

BENKELMAN Beam for Bitumen Testing - Lightweight Aluminium construction Ease of Transportation, Unique Telescopic Design Simplifying Field set up. Compact, Thereby reducing the amount of storage space needed. Benkelman Beam utilizes the technique of using balanced beam in conjunction with a suitable vehicle to measure road flexure The improved Benkelman Beam is a convenient, accurate device for m....

Loss on Heating (Thin Film Oven) For Testing Lab for Bitumen Testing Lab

NBTE-M21

Loss on Heating(Thin Film Oven) for Bitumen Testing - This dual purpose oven is designed to determine the loss in weight of bitumen and flux oils (Loss on Heating test) and the effect of heat and air on asphaltic materials (Thin Film test). The unit is heavily insulated and has a double glass door for viewing the test chamber thermometer and samples. Temperature is controlled at 163� C A....

Rolling Thin Film Oven For Testing Lab for Bitumen Testing Lab

NBTE-M22

Rolling Thin Film Oven for Bitumen Testing - The Rolling Thin Film Oven Test is used to obtain homogeneously aged material by the application of heat and air in order to simulate these affects in conventional mixing. The oven is of double wall construction with side vents and of the heated convection type of air Circulation. An electronic controller maintains the temperature at 163+ 0.5� C.....

Automatic Road Unevenness Recorder For Testing Lab for Bitumen Testing Lab

NBTE-M23

Automatic Road Unevenness Recorder for Bitumen Testing - for engineering comprises of a trailer of single wheel with a pneumatic type mounted on chaise over which are installed profile recording and integrating devices. The machine has panel board fitted with two nos. of electronic counters for counting the unevenness index value. The digital meter for unevenness index value from 50 mtrs. To 1000 ....

Compaction Pedestal For Testing Lab for Bitumen Testing Lab

NBTE-M24

Compaction Pedestal (NBTE-M24) for Bitumen Testing - Comprising a 300mm sq x 25mm thick steel plate complete with 4 tie rods and securing nuts. A mould clamp and hammer guide are fitted to the plate. The unit is supplied complete with a laminated hardwood block. Compaction Pedestal (NBTE-M24A): Comprising a 12� square x 1 inch thick steel plate secured to an 8� square x 18� h....
