Cement Testing Equipments

Cement Testing Equipments

Cement Sampler For Testing Lab for Cement Testing Lab

NCMT-E1

Cement Sampler for Cement Testing - This is a brass tube approximately 53 cm long and 2.8 cm I.D. with a wooden handle. Total length approximately 73cm. The tube has the sharp angular edge which conveniently pierces cement bags. An air hole of approximately 3mm dia is drilled on the tube near handle. Total sample collected at one time is 300 cm approximately

Blaine's Air Permeability Apparatus For Testing Lab for Cement Testing Lab

NCMT-E2

Blaine\'s Air Permeability Apparatus for Cement Testing - The apparatus is used for determining the fineness of cement in terms of specific surface expressed as total surface area in square centimeters per gram of cement. This is a variable flow type are permeability. Specification: The apparatus consists one each of permeability cell 12.5mm I.D. manometer \'U\' type mounted on stand....

VICAT Needle Apparatus For Testing Lab for Cement Testing Lab

NCMT-E3

VICAT Needle Apparatus for Cement Testing - This instrument is used for determining the normal consistency and setting times of cement and \'A\' class limes. The apparatus consists of a metallic frame bearing a freely movable and with a cap at top, one vicat mould and glass base plate and one set of needles one each initial needle, final needle and consistency plunger.

VICAT Needle Apparatus with Dashpot For Testing Lab for Cement Testing Lab

NCMT-E4

VICAT Needle Apparatus with Dashpot for Cement Testing - Same as Vicat Needle Apparatus but in addition is fitted with a dashpot which facilities gentle lowering of the needles. Accessories: Mild steel base plate 5 inches x 5 inches. Fulcrum mould, brass, 70mm i.d. base dia x 60mm i.d. top dia, 40 mm height. Note: 1) Normally set of needles and mould which meet is requirements as per I.S. 551....

Ring Mould For Testing Lab for Cement Testing Lab

NCMT-E5

Ring Mould for Cement Testing - Consists of mould 10cm x 0.5cm. Deep and a glass base plates.

GILLMORE Needle Apparatus For Testing Lab for Cement Testing Lab

NCMT-E6

GILLMORE Needle Apparatus for Cement Testing - This instrument is used for determining the time setting of hydraulic cement. A base with a Vertical shaft and Two horizontal arms. The lower arms is adjustable for height. 1 no. Initial needle 1/12-inch dia ¼ lb. Wt. 1 no. Final needle 1/24 inch dia. ¼ lb. Wt. 1 no. Glass base plate. Complete as above.

Flow Table For Testing Lab for Cement Testing Lab

NCMT-E7

Flow Table for Cement Testing - This is used for determining the workability of building limes. The flow table consists of a 30 cm dia polish steel plate with 3 engraved annular circles 7, 11 and 19cm dia. The table top is arranged for a free fall of 12.5mm by a cam action. Supplied complete with one brass conical mould, 65mm i.d. at base and 40mm i.d. at top, height of the mould 90mm.

Flow Table: for determining the flow of cement concrete For Testing Lab for Cement Testing Lab

NCMT-E8

Flow Table for Cement Testing - determining the flow of cement concrete. Consists of a steel table top 76.2cm (30 inch. Dia) Finely machined. The integral cast ribs are designed for support and strength. The stand is fabricated out of cast iron and is of study construction. Holes for mounting in foundations are drilled in the base plate. The ground and hardened steel cam is designed to fit and dr....

Flow Table (Motorised) For Testing Lab for Cement Testing Lab

NCMT-E9

Flow Table (Motorised) for Cement Testing - Same as above but electrically operated to raise and drop the table top, approx. 15 times in 15 seconds, Suitable for operation on 230 Volts, 50 cycles, A.C. supply.

Flow Table: Used for measuring the consistency of pozzolana For Testing Lab for Cement Testing Lab

NCMT-E10

Flow Table for Cement Testing - This used for measuring the consistency of pozzolana and also cement mortar and hydrated lime. It consists of a machined brass table top 250+/- 2.5mm dia. Mounted on a rigid stand. The table top is reinforced with equally disposed ribs and allowed to conical brass mould 100mm i.d. top dia and 50mm high. Accessories : Mild steel plate 25mm thick and 25cm square for....

Flow Table (Motorised) -Used for measuring the consistency of pozzolana For Testing Lab for Cement Testing Lab

NCMT-E11

Flow Table (Motorised) for Concrete Testing - Same as above but electrically operated. Fitted with a motor, connected to the cam shaft through a reduction gear to give approximately 100 R.P.M. Suitable for operation in Single Phase 230 V A.C. 50 Cycles, Supply.

LE Chatelier Mould For Testing Lab for Cement Testing Lab

NCMT-E12

LE Chatelier Mould for Cement Testing - It is used for the determination of soundness by expansion method of ordinary and rapid hardening Portland cement, low heat Portland cement and class \'A\' Limes. Specification : It consists of a small split cylinder forming a mould. On either side of the split cylinder. Two parallel indicating arms with pointed ends are attached. Supplied complete ....

LE Chatelier Water Bath For Testing Lab for Cement Testing Lab

NCMT-E13

LE Chatelier Water Bath for Concrete Testing - Double walled inner chamber in stainless steel outer chamber in mild steel temperature range Ambient to 100°C controlled by capillary thermostat. Accuracy ± 1°C operated on 230V A.C. Single Phase. These baths are suitable for washing Marshall specimen. Lid is made up of stainless steel with a hole for glass thermometer to penetrate. Fo....

LE Chatelier Flask For Testing Lab for Cement Testing Lab

NCMT-E14

LE Chatelier Flask for Cement Testing - Used for finding specific gravity of hydraulic cement. Made from Borosilicate glass. The flask is 243mm in total height, having a bulb of 90mm dia of 250ml approximate capacity. The long neck of the flask has at top a funnel of 50mm dia in that fits a ground glass stopper. The neck has over-all 11mm i.d. upper portion is graduated from 18ml to 24ml with 1 ml....

Shrinkage Bar Mould (One Gang) For Testing Lab for Cement Testing Lab

NCMT-E15

Shrinkage Bar Mould (One Gang) for Cement Testing - The mould is used for casting specimens of cement & aggregate combinations for measuring the potential expansive alkali reactivity. Specification : The mould, which has 25 mm x 25 mm x 250 mm, effective gauge length is made of mild steel and has accurately machined faces. The parts of the moulds are tight fitting and firmly held together whe....

Shrinkage Bar Mould (Two Gang) For Testing Lab for Cement Testing Lab

NCMT-E16

Shrinkage Bar Mould (Two Gang) for Cement Testing - The mould is used for casting specimens of cement & aggregate combinations for measuring the potential expansive alkali reactivity. Made of mild steel and has accurately machined faces. The parts of the moulds are tight fitting and firmly held together when assembled. Supplied complete with base plate and four stainless steel smooth reference....

Shrinkage Bar Mould (Three Gang) For Testing Lab for Cement Testing Lab

NCMT-E17

The mould is used for Cement Testing - casting specimens of cement & aggregate combinations for measuring the potential expansive alkali reactivity. The mould, with three compartments is made of mild steel and has accurately machined faces. The parts of the moulds are tight fitting and firmly held together when assembled. Supplied complete with base plate and four stainless steel smooth refer....

Shrinkage Bar Mould (Four Gang) For Testing Lab for Cement Testing Lab

NCMT-E18

Shrinkage Bar Mould (Four Gang) for Cement Testing - The mould is used for casting specimens of cement & aggregate combinations for measuring the potential expansive alkali reactivity. Bar mould as above but in gun metal as well as with knurled and threaded reference pins are also available. Spares: Stainless steel smooth or knurled and threaded reference pins as required. Supplied in Packs of....

Length Comparator For Testing Lab for Cement Testing Lab

NCMT-E19

Length Comparator for Cement Testing - It is used to measure the dying shrinkage of concrete autoclave expansion of Portland cement and potential expansive reactivity of cement aggregate combinations in mortar bars during storage, on self drying. Specification : The instrument consists of a channeled base over which two vertical pillars are fixed. An adjustable cross plate is at the top. A dial g....

Volume Change Apparatus For Testing Lab for Cement Testing Lab

NCMT-E20

Volume Change Apparatus for Cement Testing - The instrument is used for determining the volume change of cement concrete. The apparatus comprises of one mould effective gauge length complete with base plate, four reference pins, one length comparator frame, one stainless reference bar with insulated grip, and one dial gauge, 0.002mm x 10mm

Laboratory Cement Autoclave For Testing Lab for Cement Testing Lab

NCMT-E21

Laboratory Cement Autoclave for Cement Testing - he autoclave is suitable for conducting accelerated soundness tests on cements or the autoclave expansion test requiring constant steam pressure with the correspondent constant pressure. It consists of a stainless steel cylinder with a welded heat insulated metal housing attractively finished. The attached control unit encloses a sensitive pressure ....

Heat of Hydration Apparatus For Testing Lab for engineering schools

NCMT-E22

Heat of Hydration Apparatus for Cement Testing - This equipment is required to determine the heat of hydration of cement as expressed in calories per gram. The equipment comprises of the following : 1) A wide mounted double walled vacuum flask with a stop cock 38 mm & a insulating container for the flask 2) A Beckman thermometer (Range 5° C )held tightly by the cock stopper in such a wa....

Flame Photometer For Testing Lab for Cement Testing Lab

NCMT-E23

Flame Photometer for Cement Testing - MICROPROCESSOR BASED FLAME PHOTOMETER is an ideal instrument for the determination of Sodium, Potassium, Calcium and Lithium. It uses the latest Micro-controller technology and advanced engineering techniques so as to give enhanced accuracy and reproducibility. The System has 3 point calibration facility using curve fitting software. It has soft touch membrane....

Tensile Strength Tester (Hand Operated) For Testing Lab for Cement Testing Lab

NCMT-E24

Tensile Strength Tester (Hand Operated) for Cement Testing - Using for making tensile strength test on cement briquettes. Specification : A loading Machine, double lever type, with steel scale marked from 0-500 Newtons in 10 Newton division. Maximum loading capacity 5 kN. Automatic Loading system using Lead Shot. Lead shot 15 kg supplied with the machine. Set of weights for weighing lead shot com....

Tensile Strength Tester (Electrically Operated) For Testing Lab for Cement Testing Lab

NCMT-E25

Tensile Strength Tester (Electrically Operated) for Cement Testing - The instrument employs a friction free, accurate, double lever system, the load being applied by means of sliding weight on the top lever. The capacity of the units is 900 kgs. After fixing the briquette in the jaws, the machine is switched on. The sliding weight slides over the calibrated lever thus applying tension to the spec....

Briquette Mould (Single) For Testing Lab for Cement Testing Lab

NCMT-E26

Briquette Mould (Single) for Cement Testing - casting of cement briquettes for tensile strength tests. It is a two part split mould made of gun metal. Two thumb screws facilitate easy and quick assembling and dismantling of the mould. The minimum cross section of the briquettes cast is 25.4 mm x 25.4 mm. Supplied complete with a steel base plate.

Briquette Mould (Three Gang) For Testing Lab for Cement Testing Lab

NCMT-E27

Briquette Mould (Three Gang) for Cement Testing - casting three cement briquettes at a time for the tensile strength test on cement.

Standard Spatula For Testing Lab for Cement Testing Lab

NCMT-E28

Standard Spatula for Cement Testing - use while casting a cement briquette. The standard spatula consists of a steel blade, of a special shape. A wooden handle is fixed to the stem of blade. The weight does not exceed 340 gms.

Flexure Testing Machine (Motorised) For Testing Lab for Cement Testing Lab

NCMT-E29

Flexure Testing Machine (Motorised) for Cement Testing - It is used for testing 40mm x 40mm x 160mm mortar specimens for flexural strength. (Rilem Cembureau Test) by single point loading. It is motorised, Mechanical unit. The speed is adjusted so that the load increase on the specimen is between 4 to 6 kg/sec. A flexural test attachment for keeping the specimen in position is also supplied. This c....

Jolting Apparatus For Testing Lab for Cement Testing Lab

NCMT-E30

Jolting Apparatus for Cement Testing - making standard rectangular specimens of 40 x 40 x 160mm. of Portland and pozzolana cement mortar for determining the transverse strength. Specification : The jolting apparatus consists of a rectangular table rigidly connected by two support arms to a spindle at a horizontal distance of 800 mm from the centre of the table. There is a projecting lug with a pl....

Prism Mould Three Gang For Testing Lab for Cement Testing Lab

NCMT-E31

Prism Mould Three Gang for Cement Testing - supplied complete with base. All parts are marked with thei dentification number for correct assembly. Each mould is individually verified in the dimensional tolerances, hardness, squareness, flatness & roughness.

Mortor Mixer For Testing Lab for Cement Testing Lab

NCMT-E32

Mortor Mixer for Cement Testing - Used for mixing cement pastes, mortars and pozzolana. The apparatus consists of an epicyclical type stainless steel paddle imparting both planetary and revolving motion, by means of gears. It has two speeds of 140 + 5 R.P.M. And 285 +10 R.P.M. With planetary motions of approximately 62 r.p.m, +5 R.P.M. And 125 R.P.M. +/- 10 R.P.M. Respectively. The stand of the mi....

Vibrating Machine For Testing Lab for Cement Testing Lab

NCMT-E33

Vibrating Machine for Cement Testing - Concrete moulds are easily cast by using a tamping bar or a vibrating table. However air trapped in cement mortar paste can not be thus removed while casting cement mortar moulds. Easy method is to impart greater vibrating of lesser amplitude to the mould while casting This is achieved in a vibrating machine. Vibrating machine is used for the preparing of mo....

Gauging Trowel For Testing Lab for Cement Testing Lab

NCMT-E34

Gauging Trowel for Cement Testing - Weight approximately 210 gms.. Best quality with hard wood handle blade length 200mm. Trowel : 100 to 150mm long steel blade with straight edges.

POZZOLANA Cement Mortar Permeability Apparatus (Three Cell Model) For Testing Lab for Cement Testing Lab

NCMT-E35

POZZOLANA Cement Mortar Permeability Apparatus (Three Cell Model) for Cement Testing - water proofing of concrete admixture and special water proof cements are used. Water proofing of these compounds, is established by measuring permeability of standard mortar. Specimen with or without such water proofing compounds. Permeability apparatus in used to determine permeability to water of cement mortar....
