3 Phase Synchronous Machine for Electrical Lab

3 Phase Synchronous Machine for Electrical Lab

Product Supply Code: ADM-009-NE

Details for 3 Phase Synchronous Machine for Electrical Lab

3 Phase Synchronous Machine for Electrical Lab for Electric Motors Teaching Labs - This Model is the Educational model suitable for demonstrating to students the complete know of the Basics, Components, Starting methods, DC Speed locking, Speed-Torque behavior, Wear & Tear & Maintenance of these motors packaged in small rating. Students can make connections of their own with the help of the terminations provided for study of features viz Starting methods, Speed control, Speed-Torque, Speed locking, Effect of rotor excitation, Effect of voltage imbalance operation, Blocked rotor test. Technical Specs : Power ratings available : 350W / 750W / 1KW /2 KW / 3KW/ 5KW Voltage Input: 440V AC 50hz & Additionally 110V DC for Rotor RPM: 1440 / 2880 RPM Single / Double shaft extension, SPDP, IP23, IC01, B3, Class-B, S1,Solid yoke List of Experiments: Starting by DOL Starter Starting by reduced voltage starter. Effect of High voltage induction at time of starting DC Speed locking Speed Control by VVVF method Load test & No load test of machine Speed-Torque Analysis Voltage-Speed Analysis Speed reversal Efficiency Analysis Blocked rotor test Motor Operation Generator Operation Cold Resistance & Hot Resistance Motor Operation parameters Basic Overhauling Know how.
