Soil Testing Equipments

Do you know the importance of soil testing lab equipments? Have you ever thought how farming and agriculture is possible without soil testing apparatus? Soil testing is actually very important for analyzing the soil pH, exchangeable acidity and humic matter. Soil testing apparatus are very helpful for experts and scientists who want to do some research work associated with soil. Soil science is associated with the survey and examine of soil as a natural source, and in agricultural uses, this refers to measuring its properties and functions in order to enable crops and plants to flourish. Soil testing lab equipments are made of various types of metal, glass, copper, zinc and various other materials. They are actually very helpful to save money & time as well as economical. These Soil testing lab equipments play a prime role to perform some significant tests or experiments, analysis and examines related to soil. These are completely multipurpose for agriculture and extremely useful in analyzing the nutritional level of soil. Naugra Lab is the prestigious name in the exporting of soil testing lab equipments with superior quality apparatus as every client wants. As a commendable soil testing equipments exporters for OEM orders and Tenders, we assure complete client satisfaction. These soil science lab equipments are great to analyze the level of phosphorous, nitrogen, saline content, potassium, moisture and PH level. In addition, the devices are also good to check the current pH level of the agriculture land

Plastic Limit Test For Testing Lab for Soil Testing Lab

NSOL-T1

Plastic Limit Test for Soil Testing - Moisture contents at which soil has smallest plasticity is called limit. For determination purpose plastic limit is defined as the water content at which a soil will just begin to crumble when rolled in to a thread of 3mm dia. Specification : The complete set consists of one each : 1. Glass plate 20cm x 15cm having round ends 2. Brass or stainless steel ro....

Shrinkage Limit Set For Testing Lab for Soil Testing Lab

NSOL-T2

Shrinkage limit for Soil Testing - is the maximum water content at which a reduction in water content does not cause an appreciable reduction in volume of the Soil Mass. At shrinkage limit, on further reduction in water, air enters in to the voids of soils and thus keeps the volume constant. The apparatus can be used to determine shrinkage limit and to calculate other shrinkage ratio, shrinkage i....

Linear Shrinkage Mould For Testing Lab for Soil Testing Lab

NSOL-T3

A simple mould which is filled with the soil under test for Soil Testing - This is then dried and the resulting decrease os length of the specimen measured is expressed as the linear shrinkage. It is 25mm Dia. x 12.5mm Height x 140mm Length.

Soil Cone Penetrometer For Testing Lab for Soil Testing Lab

NSOL-T4

For determining the liquid limit of soil for Soil Testing - . This is specially useful to obtain reliable and accurate results of those soil which have low plasticity index. The percentage moisture contents determined when cone with half angle of 15-30 minutes under a total sliding weight of 148 gm penetrates 25mm gives the liquid limit.

Semi Automatic Cone Penetrometer For Testing Lab for Soil Testing Lab

NSOL-T5

for Soil Testing - Used to determine the moisture content at which clay soils pass from a plastic to a liquid state. Two Version are available. One the standard one & the other is semi-automatic with timer where the cone is allowed to free fall for a period of 5 seconds including one each of 50 gm. & 100 gm. weight, one penetration cone, preset counter & measuring cup.

Liquid Limit Device For Testing Lab for Soil Testing Lab

NSOL-T6

Liquid Limit Device & Liquid Limit Device for Soil Testing - (with Counter) Casagrande method in mechanical form is known as liquid limit method and has been in use for soil mechanics for a number of decades. The liquid limit data of soils is useful to correlate mechanical properties of soil, such as compressibility and lower shear strength. Liquid limit is the water content at which soil pas....

High Speed Stirrer For Testing Lab for Soil Testing Lab

NSOL-T7

for Soil Testing - This is for mechanical analysis and also other laboratory applications for stirring Speed approximately 4000 R.P.M. under load. A dispersion cup is supported on a rest on the stand of the stirrer and has a removable baffle. For operation on 230V A.C. supplied with dispersion cup or baffle cup.

Grain Size Analysis Pipette Met For Testing Labhod for Soil Testing Lab

NSOL-T8

for Soil Testing - This is for the determination of the sub sieve particle distribution in a soil sample by mechanical analysis. An analysis of this kind expresses quantity the proportions by weight of the various sizes of particles present in the soil. It is recommended as a standard procedure to use dispersion agent to avoid flocculation. The apparatus consists of a sliding panel which moves up ....

Particle Size Sedimentation By Hydrometer Method For Testing Lab for Soil Testing Lab

NSOL-T9

for Soil Testing - Particle size analysis of soils: Hydrometer method This equipment is used to determine the quantitative size distribution of very fine particle in soils such as clay and silt. The complete set comprises: 1. SEDIMENTATION CYLINDER, 1000 ml capacity (6 pieces) with rubber bungs. 2. SOIL HYDROMETER, 151H, range 0.995 to 1.038 g/ml with div. 0.001 3. GLASS TANK, dimensions: 600x....

Soil Hydrometer For Testing Lab for Soil Testing Lab

NSOL-T10

for Soil Testing - Used for grain size analysis of soils where more than 10% of the material will pass through 75 microns B.S. sieve. Manufactured from clear transparent glass having uniform clarity throughout the upper end on which density scale is engraved. The scale range is 0.995 to 1.030 0 density (gms./cc) at 27oC smallest division on the scale is 0.0005. NOTE : Hydrometer for other liquids....

Sand Equivalent Test Set For Testing Lab for Soil Testing Lab

NSOL-T11

for Soil Testing - Used to determine the relevant proportions of clay-like or Plastic fines and dust in granular soils & fine aggregate Consists of: Acrylic graduated cylinder (4 nos.), Rubber stopper for cylinder (4 nos.), Graduated Steel rule 450 mm, Funnel 100 mm plastic, Aspirator bottle 5 lts plastic with rubber cock, Stand for the aspirator bottle with siphon assembly, Irrgation tube wi....

Motorised Sand Equivalent Shaker Set For Testing Lab for Soil Testing Lab

NSOL-T12

for Soil Testing - The unit provides a constant uniform shaking with automatic cycle test. Oscillating excursion is 200 mm at 175 strokes / minute rate. Complete with timer that automatically stops the shaker at the end of the test. Power Supply 230 V A.C. 50Hz.

Liquid Limit Device (Motorised) For Testing Lab for Soil Testing Lab

NSOL-T13

Liquid Limit Device (Motorised) for Soil Testing - Fitted with a motor geared down to give approximately 120 rpm. Suitable for operation on 230 V A.C., Single Phase, 50 Cycles. Casagrande method in mechanical form is known as liquid limit method and has been in use for soil mechanics for a number of decades. The liquid limit data of soils is useful to correlate mechanical properties of soil, such ....

Plummet Balance For Testing Lab for Soil Testing Lab

NSOL-T14

for Soil Testing - Conventionally particle size distribution analysis is carried out using pipette and hydrometer methods. Whereas in hydrometer method it is possible to determine particle sizes in the range 75microns, the method involves computation and it is time consuming. The pipette method can be used for determining only the percentage of specific sizes less than 0.02, 0.006 and 0.002mm as a....

Marsh Cone For Testing Lab for Soil Testing Lab

NSOL-T15

for Soil Testing - This cone is used to find out viscosity of bentonite slurry and similar material. The marsh cone is 6 inch in diameter at the top and 12 inch long, and tapers to join a tube 2 inch long and 3/16 inch inside dia. The capacity of the funnel is 1500cc. Time in seconds required to flow out 1000cc of slurry from cone is measured as funnel viscosity of the material.

Mud Balance For Testing Lab for Soil Testing Lab

NSOL-T16

for Soil Testing - Designed to find out specific gravities of semi liquids like mud and other liquids having densities in the range 0.8 to 2.5. It has a stainless steel bam calibrated specific gravities from 0.8 to 2.5. A stainless steel cup with lid and overflow vent is fitted on one side of the beam. A counter weights with cursor slides over the graduated scale. The beam has a knife-edge at cent....

Standard Compaction Test For Testing Lab for Soil Testing Lab

NSOL-T17

for Soil Testing - The apparatus consists one each of compaction mould steel, 100 mm I.D. x 127.3mm height x 1000 cc. volume, complete with collar and base plate. Compaction Rammer is 2.6 kgs in weight x 310mm controlled fall. Standard Compaction Test : The apparatus consists one each of compaction mould steel, 105mm I.D. x 115.5mm height x 1000 cc. volume, complete with collar and base plate. Co....

Heavy Compaction Test For Testing Lab for Soil Testing Lab

NSOL-T18

Heavy Compaction Test for Soil Testing - The apparatus consists one each of compaction mould steel, 152.4mmI.D. x 116.4mm height x 2124 cc. volume, complete with collar and base plate Compaction Rammer is 4.5 kgs. in weight x 18” controlled fall. Face of the rammer is 2” Heavy Compaction Test : Instrument consists one each of compaction mould steel 150 mm I.D. x 127.3mm height volume ....

Semi-Automatic Compactor For Testing Lab for Soil Testing Lab

NSOL-T19

Semi-Automatic Compactor  for Soil Testing - A mechanically cum electrically operated semi-automatic compactor is therefore deviced to eliminate hand compaction process. Which also considerably saves time with the Rammers provided two stroke lengths, available, the compactor can be used for normal compaction/heavy compaction as well as C.B.R compaction. Specification : It is a motor driven....

Universal-Automatic Compactor For Testing Lab for Soil Testing Lab

NSOL-T20

Universal-Automatic Compactor  for Soil Testing - Universal-Automatic Compactor : ZI 3017-B ASTM D 558, BS 1377-4 It is a motor driven mechanical compactor useful for soil compaction into 100mm to 102 mm & 150mm to 152.4 mm diameter moulds. Two sets of Rammers are provided, one of 2.5 kg and arranged for 300 mm & 305 mm drop and other 4.5 kg and arranged for 450 mm & 457 mm d....

Proctor Needles (Spring Type) For Testing Lab for Soil Testing Lab

NSOL-T21

for Soil Testing - The instrument consists of a needle attached to a spring loaded plunger, the stem of which is calibrated to read 0 to 40 kg division. Long stem is graduated at every 12.5mm to read depth of penetration and for use with needles of larger areas. The small penetration stem is also graduation in 12.5mm division and is used with needles of smaller areas. Needle points one each of 0.2....

Proctor Needles (Hydraulic Type) For Testing Lab for Soil Testing Lab

NSOL-T22

for Soil Testing - This is identical to ZI 3018, except that the penetration pressure on the needle is conveyed through a hydraulic system to a hydraulic pressure gauge. This system permits a greater control over rate of penetration because of better visibility of load indication on the gauge. Specification : Comprises hydraulic proctor needle system complete with a pressure gauge fixed at easil....

Pocket Penetrometer For Testing Lab for Soil Testing Lab

NSOL-T23

for Soil Testing - This instrument is used to estimate approximate unconfined compressive strength and the estimation to shear strength of soil Cohesive soils can also be classified in terms of consistency using this Penetrometer. This is a handy and convenient instrument. Specification : It consists of a light weight barrel assembly with a polished and ground steel loading piston plunger. A dir....

VICKSBERG Penetrometer (Proving Ring Type) For Testing Lab for Soil Testing Lab

NSOL-T24

for Soil Testing - This is fork determining the bearing capacity of sub grades or for compaction control. It also used for rapidly of soils in shallow exploration work. Consists of a study handle under. Which is fixed a sensitive proving ring. An extension piece is fixed to the bottom of the proving ring and carries a detachable penetration cone at its tip. Proving ring capacity 100 kg (1kn) and 0....

Speedy Moisture Meter (D2 Large) For Testing Lab for Soil Testing Lab

NSOL-T25

for Soil Testing - The unit consists of a pressure vessel with clamp for sealing cap, capacity is 20 gms. Rubber sealing gasket, pressure gauge calibrated in percentage moisture content 0-25% x 0.25% on the wet weight basis, an electronic balance for weighing sample, a scoop for measuring carbide reagent, a bottle of reagent, one cleaning brush and a set of 4 steel balls for thorough mixing . Comp....

Rapid Moisture Meter 0-50% For Testing Lab for Soil Testing Lab

NSOL-T26

for Soil Testing - The unit consists of a pressure vessel with clamp for sealing cap, capacity is 6 gms . Rubber sealing gasket, pressure gauge calibrated in percentage moisture content 0-50% x 0.50% on the wet weight basis, a counter poised balance for weighing sample, a scoop for measuring carbide reagent, a bottle of reagent, one cleaning brush and a set of 4 steel balls for thorough mixing . C....

Rapid Moisture Meter 0-25% For Testing Lab for Soil Testing Lab

NSOL-T27

for Soil Testing - Same as above but pressure gauge calibrated 0-25% x 0.25% SPARES : Carbide reagent, in bottles of 500 gms. each available on extra cost.

Infrared Moisture Meter For Testing Lab for Soil Testing Lab

NSOL-T28

for Soil Testing - It is a fast ,accurate method to derive direct moisture % in a sample by Loss on Heating Method. Heating arrangement consists of a 250 watt heating lamp with a solid state power stat to control rate of drying and also temperature.

Permeability Apparatus (Falling Head Permeability) For Testing Lab for Soil Testing Lab

NSOL-T29

for Soil Testing - The apparatus is used for the laboratory determination of permeability of soil using a constant or a variable head. This test is recommended for soils with co-effcient permeability in the range of 0 10-3 to 10-7 cm/sec. The maximum particle size of the soil which can be tested in the mould is 10mm. The equipment comprises one each : Gun metal mould, 100mm I.D. x 127.3mm high x 1....

Universal Permeability For Testing Lab for Soil Testing Lab

NSOL-T30

for Soil Testing - Same as above but instead of a set of three glass stand pipes a stand with nine glass tubes of 6mm, 10mm, 20mm, 25mm, 40mm, 50mm, 60mm, 70mm, 75mm, bore tube is provided with over flow arrangement for constant head tests. The remaining tubes are used for falling head test.

Sand Pouring Cylinder For Testing Lab for Soil Testing Lab

NSOL-T31

for Soil Testing - This apparatus is used for the in place determination of the dry density of compact, line and medium grained soils and for layers not exceeding 50cm thickness. The complete apparatus consists one each of Small sand pouring cylinder, 3 litre capacity fitted with conical funnel and shutter. Cylinder calibrating container, internal dia 10cm and internal depth 15cm dia hole in the c....

Sand Density Cone Apparatus For Testing Lab for Soil Testing Lab

NSOL-T32

for Soil Testing - Used to determine the in-situ density of fine grained compacted soil. The test consist in digging a hole into the ground and then collect, dry and weight the sampled soil. The hole is then filled with dry sand from the cone container. The apparatus consist of a double metal cone, one plastic 5 lts jar & a metal tray with centre hole. Size of the cone is 6½” (165....

Core Cutter For Testing Lab for Soil Testing Lab

NSOL-T33

for Soil Testing - This is used for determination of in situ dry density of natural or compacted fine grained soil, free from aggregates. A cylindrical cutter is used to extract a sample of the soil with the help of a dolly and rammer. From the weight, density and the moisture, and dry density of the soil is ready calculated. It consists one each of: cylindrical core cutter mode of steel, 127.3mm.....

Pycnometers For Testing Lab for Soil Testing Lab

NSOL-T34

Pycnometers for Soil Testing - Useful to determine specific gravity of clays, sand and gravel of size smaller than 10mm. Comprises a 1 kg. glass jar with brass cone. Locking ring and rubber seal. SPARE : Rubber seal.

Density Bottle (GAY-LUSSAC Type) For Testing Lab for Soil Testing Lab

NSOL-T35

For determining the particle density (specific gravity) for Soil Testing - of sand, fine aggregate & filler. Capacity 25ml, 50ml, 100ml, 250ml, 500ml & 1000ml.

Particle Density by Gas Jar Method (End-Over-End Shaker) For Testing Lab for Soil Testing Lab

NSOL-T36

for Soil Testing - This method applies for soil containing upto 10% of particles retained on 37.5 mm sieve. The equipment is used to rotate two gas jars at approx. 50 R.P.M..Glass Jar is 1 litre in capacity with rubber bung.

Relative Density Test For Testing Lab for Soil Testing Lab

NSOL-T37

for Soil Testing - The equipment is used for the determination of the relative density of cohesion less free draining soils and meets the essential requirements. The equipment consists one each of: Vibratory table, with a cushioned steel vibrating decks about 75cm x 75cm. It has a frequency of approximately 3600 vibratory table, minute under a 11.5kg load. Amplitude is variable in between 0.65mm ....

Soil Testing Kit For Testing Lab for Soil Testing Lab

NSOL-T38

for Soil Testing - A very useful kit to determine on the spot soil pH value. This is a compact kit easy to carry on site. CONSISTS OF : 12 thick walled test tubes with rubber bungs. 1 tube Cleaning brush. 1 bottle of Barium Sulphate (100gm). 1 bottle of Soil indicator (100gm). 1 bottle of Distilled water (500gm). 1 Spatula. 1 Colour chart, range 4.0 to 8.0 ph in 0.5 ph steps. Complete with carry....

Water Testing Kit For Testing Lab for Soil Testing Lab

NSOL-T39

for Soil Testing - ACIDITY TESTING KIT, CHLORIDE TEST KIT, HARDNESS TEST KIT, SOIL COLOUR CHART

Colour Standard Chart For Testing Lab for Soil Testing Lab

NSOL-T40

for Soil Testing - Colour Standard Chart For the determination of organic impurities in soils and fine aggregates.

Earth Resistivity Meter For Testing Lab for Soil Testing Lab

NSOL-T41

for Soil Testing - Capable of measuring earth voltage (V A.C.) 2mA measuring current permits the testing of earth resistance without tripping earth leakage current circuit breakers in the circuit. Auto power off function. The timer operates auto power off function. The time operates the \\\"PUSH BUTTON SWITCH\\\" and \\\"TIMER ON BUTTON\\\' are pressed together. This will keep ....

Extractor Frame Universal (Screw Type) For Testing Lab for Soil Testing Lab

NSOL-T42

for Soil Testing - Designed to extract specimens from almost every type of sampling tube and mould used in solid engineering laboratory or in the field. It can be mounted vertically or horizontally as desired. It has an unique feature that three 38mm dia sample. SPECIFICATION: Comprises of a frame designed for screw jack operation, one each of the adaptors for 38mm, 75mm, 100mm, 150mm dia meter ....

Soil Trimmer (Hand Operated) For Testing Lab for Soil Testing Lab

NSOL-T43

for Soil Testing - For trimming various diameter specimen for triaxial and unconfined compression tests. SPECIFICATION: The lower specimen grip is mounted on a disc which rotates freely. The soil sample is mounted on the lower specimen grip and the upper grip is firmly seated on top of the specimen. The vertical guide can be adjusted to control the depth of cut. While trimming the lower disc is ....

Soil Lathe (Motorised) Bench Mounting For Testing Lab for Soil Testing Lab

NSOL-T44

for Soil Testing - This instrument is used for preparing soil samples for various tests like Triaxial Test, Unconfined Compression Test etc. Soil lathe consist of a cabinet enclosing motor and gear system which rotates a disk at 24 R.P.M. this disc adopts gripper plate of various size. An up right has an adjustable holder and takes upper gripper plates of different diameters. Arrangement is provid....

Constant Volume Mould For Testing Lab for Soil Testing Lab

NSOL-T45

for Soil Testing - For specimen size 38mm x 76mm long comprises. Split mould 38mm dia x 126mm long. End plug 38mm dia x 25mm long pair. Split collar interchangeable. Ejecting plunger 38mm dia x 126mm long. ACCESSORIES : Split mould 38mm dia x 76mm long and split mould 38mm dia x 86mm long.

Consolidation Apparatus (Single Gang) For Testing Lab for Soil Testing Lab

NSOL-T46

for Soil Testing - Consolidation test is un-dimentional test considered extremely important in soil mechanics. Sample taken from adjacent areas of a single site show differential settlement even when tested using same techniques. Soil of similar strength may show varying consolidation. Samples are very carefully prepared and vertical settlement of the specimen in saturated or drained conditions ca....

Consolidation Apparatus (Front Loading Type) For Testing Lab for Soil Testing Lab

NSOL-T47

for Soil Testing - Rigidly manufactured from aluminium alloy casting to provide a high degree of accuracy with any frame distorsion under load. The load bridge group is supported in high accuracy self-aligning seat balls. The beam provides three loading ratio: 9:1 10:1 11:1 and the beam assembly is fitted with an adjustable counterbalance weight. Maximum load: 150 kg of slotted weights. The odeome....

Consolidation Apparatus (Floating Ring Type) For Testing Lab for Soil Testing Lab

NSOL-T48

Water trough for Soil Testing - Floating ring type of Consolidometer (Odeometer) cell assembly for 60mm dia x 20mm thick specimens complete with floating ring with two guide rings, pair of porous stones, pressure pad and cutting collar. Set of weights to give a pressure of 10kg/cm. sq. on 60mm dia specimens. Floating ring type of Consolidometer (Odeometer) cell assembly for 50mm dia x 20mm thick ....

Consolidation Apparatus (Three Gang Model) For Testing Lab for Soil Testing Lab

NSOL-T49

for Soil Testing - Rigidly manufactured from aluminium alloy casting to provide a high degree of accuracy with any frame distorsion under load. The load bridge group is supported in high accuracy self-aligning seat balls. The beam provides three loading ratio: 9:1 10:1 11:1 and the beam assembly is fitted with an adjustable counterbalance weight.

Consolidation Apparatus (Electronic Bench Model) For Testing Lab for Soil Testing Lab

NSOL-T50

for Soil Testing - Same as ZI 3048 except that the data is displayed and acquired in the digital electronic system. Unit confirms To BS 1377:5 standard.
