Product Code: TechnicalLab0510
We are leading manufacturers, suppliers & exporters of Farm Diesel Engine Tractor Cutaway Trainer. Contact us to get high quality designed Farm Diesel Engine Tractor Cutaway Trainer and Lab Education & Training Products for schools, colleges, TVET, universities, training laboratory, research lab, hospital and medical lab and various Industrial Laboratory Training Program. We accept bulk orders for government tenders in all countries around the globe.
Equipment Available for bulk tender supply, exports & turnkey lab projects worldwide. Send us your tender BOQ for a fully compliant quote.
The Farm Tractor Cutaway Trainer – 4-Cylinder Diesel Engine is a fully operational educational model designed to demonstrate the construction, operation, and maintenance of a modern agricultural tractor. Carefully sectioned for instructional purposes, the trainer exposes the internal working components of the engine, transmission, clutch, hydraulic system, and drivetrain, allowing students to gain a comprehensive understanding of tractor engineering.
The cutaway components are professionally finished with contrasting colors to clearly distinguish individual parts, lubrication passages, and sectional views. This enhances learning by making the movement and interaction of mechanical assemblies easy to identify during operation. Selected components are chrome-plated and galvanized to provide superior corrosion resistance and ensure long-term durability in educational laboratories.
The trainer is electrically powered by a 230 V AC motor, allowing the engine and transmission assemblies to operate safely at a reduced speed. This enables learners to observe the movement of gears, shafts, clutch components, hydraulic mechanisms, and drivetrain assemblies without the hazards associated with a running diesel engine.
Mounted on a heavy-duty steel stand with industrial wheels, the trainer is ideal for engineering colleges, vocational training institutes, agricultural machinery training centres, and technical laboratories.
Fully functional tractor cutaway training model
Precision sectioned engine and transmission assemblies
Professionally color-coded internal components
Electrically driven for safe classroom demonstrations
Reduced operating speed for clear observation of moving parts
Chrome-plated and galvanized components for enhanced durability
Heavy-duty mobile steel stand with lockable wheels
Designed for practical maintenance and technical training
Engine Type: 4-Cylinder Diesel Engine
Fuel Injection System: Rotary Fuel Injection Pump
Clutch: Single-Disc Clutch
Transmission: Multi-Speed Gearbox with Reduction Unit
Hydraulic System: Rear Hydraulic Lift
Differential: Rear Differential with Mechanical Lock
Drive System: Front-Wheel Drive Engagement Mechanism
Operation: Electrically Driven
Power Supply: 230 V AC
Mounting: Heavy-Duty Steel Stand with Wheels
Diesel engine construction and operation
Fuel injection system demonstration
Clutch engagement and disengagement
Gearbox and reduction gear operation
Rear differential and locking mechanism study
Front-wheel drive engagement demonstration
Hydraulic lifting system operation
Lubrication system analysis
Power transmission through the drivetrain
Preventive maintenance and servicing procedures
Agricultural Machinery Training
Tractor Maintenance Education
Automotive Engineering Laboratories
Mechanical Engineering Departments
Technical and Vocational Training
Farm Equipment Service Training
Industrial Skills Development
Engineering Demonstration Laboratories
Agricultural Engineering Colleges
Engineering Universities
Technical Training Institutes
Vocational Education Centres
Automotive Training Schools
Agricultural Machinery Manufacturers
Farm Equipment Service Centres
Industrial Training Facilities
Research and Development Laboratories
