Product Code: TechnicalLab0243
Gas Engine Cut-Away, FWD, with Overhead Camshaft, Electrical Operation
The FWD Gas Engine Cut-Away with Overhead Camshaft is an operational engine mounted on a stand with wheels. This trainer contains cut-away sections that are color-coded to demonstrate the flow of oil, fuel, water, air, and exhaust gas throughout the engine and gearbox. The color coding is based on international standards.
TECHNICAL FEATURES:
Gas Engine 4 stroke, 1108cc
4 Cylinders in line with overhead Camshaft, 2 Valves per cylinder
Timing System, working with toothed belt.
Electronic Ignition with 4 spark plugs.
Single carburetor and air filter.
Mechanical fuel pump
Complete cooling system: water pump, radiator, electric fan, etc.
Alternator and starter motor.
Lubrication system with mechanical oil pump and filter.
Clutch: mechanical dry, single disc type.
Gearbox: 4 or 5 forward & reverse.
Differential with cylindrical coupling.
Front-wheel drive, transverse position, working with two axle-shafts
Braking system with: servo-brake, brake pump, tank for brake oil, and two complete disc brakes, all cut away for teaching and training purpose.
Simulation of fully operating brake, formed by: brake pump, tank for oil brake, and one complete working disc brake (really working as in a normal car).
Complete pedal board: brake-clutch-accelerator.
McPherson-type independent front suspension with helical springs.
Hydraulic shock-absorbers.
Rack and pinion steering box.
Working steering wheel.
New, cut-away battery.
Sparks plugs with light simulated explosion strokes.
