Single Cylinder Diesel Engine Test Rig
The Set-up consists of 1 Cylinder, 4 Stroke Diesel Engine connected to Dynamometer for variable loading. The Setup has stand-alone type independent panel box consisting of air box, fuel tank, and manometer, fuel measuring unit, digital speed indicator and digital temperature indicator. Engine Jacket cooling water Inlet, Outlet and Exhaust Gas Temperature is displayed on temperature indicator. Rotameters is provided for Cooling Water Flow measurement.
FEATURES:-
Compact Set-up
Digital Speed Measurement
Digital Temperature Indication
RANGE OF EXPERIMENTS:-
Study of engine performance for power, efficiencies, fuel consumption, air fuel ratio and heat balance.
UTILITIES REQUIRED:-
Electric Supply: - Provide 230 +/- 10 VAC, 50 Hz, Single Phase Electric Supply with proper earthing. (Neutral – Earth voltage less than 5 VAC)
Space: - 3800L x 2500W x 1700H in mm Foundation as per drawing supplied.
Water Supply: Continuous clean and soft water supply @ 1000 LPH, at minimum Head 20 m. is needed. Provide tap with ½” BSP size connection.
Exhaust: - Provide exhaust pipe 32 NB (1 ¼ “) size with suitable length.
Drain: - Provide drainpipe 1 ½” BSP size with suitable length.
Fuel, Oil: Diesel:10 Ltrs. Lubricating Oil: @ 5 Ltrs (20W40)
SPECIFICATIONS: -
Product: Engine Test Set-up 1 Cylinder, 4 Stroke, Diesel
Engine: Make - Kirloskar, Type 1 Cylinder, 4 Stroke Diesel,Water Cooled, Power 5 HP at 1500 RPM, Stroke 110 mm,Bore 80.0 mm. Compression ratio 16.5 : 1, Capacity 553 CC.
Dynamometer: Type Rope with Set of WeightsType Electrical with Loading Deviceype Hydraulic with Loading DeviceType Eddy Current with Loading Device
Air Box: M S Fabricated with Orifice Meter and Manometer
Fuel Tank: Capacity 15 Ltrs. With Glass Fuel Metering Column
Speed Indicator: Digital Speed Sensor
Temperature: Type Digital, Multipoint, Input K type Thermocouple Indicator
Temperature: Thermocouple, Type K Sensor
Rotameter: Range 40 – 400 LPH
A good quality painted rigid MS Structure is provided to support all the parts.
