Small Farm Tractor Cutaway Trainer 4-Stroke Diesel Engine

The Small Farm Tractor Cutaway Trainer – 4-Stroke Diesel Engine is a fully functional educational training model designed to demonstrate the construction, operation, and maintenance of a compact agricultural tractor. Precision cutaway sections expose the internal working of the engine, transmission, steering, braking, hydraulic, and drivetrain systems, providing students with an excellent understanding of tractor engineering and maintenance procedures.

The trainer has been carefully sectioned and professionally finished using contrasting colors to distinguish major components, cross-sectional areas, lubrication passages, fuel circuits, and cooling systems. This visual approach enables learners to easily identify each component and observe its function during operation. Selected components are chrome-plated and galvanized for enhanced corrosion resistance and long service life.

The model is electrically driven by a 230 V AC motor and operates at a reduced speed, allowing safe observation of moving mechanical assemblies. Students can study the operation of the diesel engine, clutch, gearbox, steering mechanism, hydraulic lift, differential, and power take-off system without the hazards associated with a running engine.

Mounted on a heavy-duty steel stand fitted with industrial wheels, the trainer is ideal for engineering colleges, vocational training centres, agricultural machinery institutes, and technical laboratories.

Key Features

• Fully operational compact tractor cutaway trainer

• Precision sectioned engine, transmission, and drivetrain

• Professionally color-coded internal components and fluid circuits

• Electrically operated for safe classroom demonstrations

• Reduced operating speed for detailed observation of moving parts

• Chrome-plated and galvanized components for long service life

• Heavy-duty mobile steel stand with lockable wheels

• Ideal for practical maintenance and technical education

Technical Specifications

• Engine Type: 4-Stroke Diesel Engine

• Engine Power: 20 HP (16 kW)

• Cooling System: Water Cooled

• Lubrication System: Trochoidal Oil Pump

• Fuel Injection System: In-Line Fuel Injection Pump

• Clutch: Dry Single-Disc Clutch

• Transmission: 6 Forward Speeds + 2 Reverse Gears with Gear Reduction Unit

• Power Take-Off: Two-Speed PTO

• Differential: Mechanical Locking Rear Differential

• Drive System: Selectable Front-Wheel Drive Disengagement

• Brake System: Rear Drum Brakes

• Steering System: Sector-Type Steering Gearbox

• Hydraulic System: Rear Hydraulic Lift

• Operation: Electrically Driven

• Power Supply: 230 V AC

• Mounting: Heavy-Duty Steel Stand with Wheels

Educational Experiments

• Four-stroke diesel engine operation

• Fuel injection system demonstration

• Cooling and lubrication system analysis

• Clutch and transmission operation

• Gear reduction mechanism study

• Power Take-Off (PTO) operation

• Differential locking mechanism demonstration

• Front-wheel drive engagement and disengagement

• Hydraulic lifting system operation

• Steering and braking system analysis

• Preventive maintenance and servicing procedures

Applications

• Agricultural Machinery Training

• Tractor Maintenance and Repair Education

• Mechanical Engineering Laboratories

• Automotive Engineering Training

• Technical and Vocational Education

• Farm Equipment Service Training

• Industrial Skills Development

• Engineering Demonstration Laboratories

Industries Served

• Agricultural Engineering Colleges

• Engineering Universities

• Technical Training Institutes

• Vocational Education Centres

• Agricultural Machinery Training Centres

• Automotive Training Schools

• Farm Equipment Service Workshops

• Industrial Training Facilities

• Research and Development Laboratories
