Vacuum Drying Oven India — specification
Made in our own plant in Ambala Cantt, the Vacuum Drying Oven India is supplied to colleges, technical institutes and industry for materials testing work, in single units or bulk. Part of our Construction Materials Testing Instruments range.
• Vacuum Drying Oven gently dries materials with homogeneous temperature distribution.
• Outer made of thick mild steel, stove enamel painted.
• Inside made of thick stainless steel.
• The shelves are easy to position where required and the inner chamber of the vacuum drying oven is easy to clean.
• Type: Vacuum Drying Oven
• Temperature range: Ambient temperature, above ambient temperature to 220 ̊C
• Vacuum data: Leak rate [bar/h): 0.01bar/h
• Capacity (Interior volume [L]): 24 L ± 10%
• Capacity shelf (Load per rack [kg]): 20 kg ± 10%
• Connections
• Vacuum connection with small flange [DN mm]: 16
• Measuring access port with small flange [DN mm]: 16
• Compressed air connection for pressure-encapsulation 5 NW
• Interior Dimension (Depth x Width x Height): 295 x 285 x 285 mm
• Electrical requirement: 220-240V, 50Hz
• Net weight of the unit (empty) [kg]: 64kg ± 10%
• Number of shelves (max.): 4
• Accessories: Vacuum pump and Vacuum pump connection kit included
• Material: Stainless steel interior
• Inert gas connection: Yes
• Controller: Digital di splay of pressure and temperature
• Program-controlled drying monitoring with automatic ventilation at end of process: Yes
• internal data logger, measured values can be read out in open format via USB: Yes
For similar products visit at main page of Construction Materials Testing Instruments.
