Variable DC Power Source (Power Distribution Panel) for Electrical Lab Manufacturer, Supplier and Exporter

Variable DC Power Source (Power Distribution Panel) for Electrical Lab

Product Code: ADM-025-NE

Details for Variable DC Power Source (Power Distribution Panel) for Electrical Lab

Variable DC Power Source (Power Distribution Panel) for Electrical Lab for Electric Motors Teaching Labs - Our specification covers design, manufacturing, inspection, testing, supply of the DRIVE. 2) INPUT SYSTEM :- Normal Voltage : 415V +/- 10% No of phases : Three phase, four wire Frequency : 50Hz +/- 2% Fault level : 20KA RMS at 415 V. Neutral earth : Solidly earthed. 3) TECHNICAL PARTICULARS :- 3.1) Output Voltage. Armature : 440V DC Max. Field : 220V DC DC Motor Blower : 415V +/-10%, 50Hz +/-2%, 3Ph. 3.2) Output Current. Armature : Field : 3.3) Speed Control. 3.4) Accuracy of speed control. +/-2% under Arm.Voltage feedback. 3.5) Soft start. Acceleration and deceleration control from 5sec to 30sec adjustable. 3.6) Type of control : Tacho/Arm. Voltage feedback. 3.7) Direction of rotation.: 3.8) Braking. 3.9) Type of cooling : Forced air cooling 4) CONVERTER MODULES. It consists of the following modules. Input module Thyristor module Regulation module Output module Excitation module Indicating and operating module Protection module 4.a Input module The incoming 415V 3PH four wire supply will be brought into this module. It consists of - Tripple pole and neutral incoming AC heavy duty isolator switch. Three nos. HRC fuse link for mains. Main contactor Line surge suppressor consisting of capacitors, resistors & MOVs. 4.b Thyristor module It will consist of three phase, full wave, fully controlled thyristor bridge assembly comprising of - Six nos. derated thyristors each mounted on Aluminium heat sinks RC Snubber circuit for power semi-conductors. MOVs to protect thyristors against spikes. Pulse transformers to isolate the control circuit from power circuit. Forced cooling arrangement. 4.c Regulation module It consists of modular glass-epoxy based printed circuit boards of height 4U with plug-in type gold plated connectors for easy replacement and servicing. These are green masked, legend printed PCBs housed in a card frame and interconnected by a mother PC Board. The different blocks are as under. Power supply and regulator. Ramp generator with adjustable accn. Decn. Circuit. Voltage and current control amplifier which controls the output voltage with adjustable voltage and current limiting. Pulse amplifier feeding the pulse transformer primary and the gate trigger cirrcuits. Tripping circuit for single phasing, phase sequence, under voltage, field failure and Electronic overload. The settings petentiometers (presets), coloured test points and LED indicators are located at the front of the cards.

We are leading manufacturers, suppliers & exporters of Variable DC Power Source (Power Distribution Panel) for Electrical Lab. Contact us to get high quality designed Variable DC Power Source (Power Distribution Panel) for Electrical Lab for schools, colleges, universities, research labs, laboratories and various industries. We accept bulk orders for government tenders in all countries around the globe.

For similar products visit at main page of AC DC Motors Machines.
