VOLTMETER CHARACTERISTICS: OHMS PER VOLT for Vocational Training and Didactic Labs

VOLTMETER CHARACTERISTICS: OHMS PER VOLT for Vocational Training and Didactic Labs

Product Supply Code: ETKN-0007

Details for VOLTMETER CHARACTERISTICS: OHMS PER VOLT for Vocational Training and Didactic Labs

Equipment for Education, Engineering and Vocational Training - Experimental Training Board has been designed specifically for the study of Voltmeter Characterstics : Ohms per volt. .
It is actual practice to specify the sensitivity of a voltmeter in terms of ohms per volt.Practical experience on this board carries great educative value for Science and Engineering Students.

OBJECT

Study of Voltmeter characteristics : Ohms per volt.FEATURES The board consists of the following built-in parts :01.Voltmeter 65mm rectangular dial of 1V range, having resistance of 1K ± 10% and full scale deflection current is 1mA.02.IC regulated variable DC power supply of 0-20Volt at 100mA.03.Necessary resistance.04.Mains ON/OFF switch, Fuse and Jewel light. *The unit is operative  on 230V  ±10% at 50Hz A.C. Mains.*Adequate no. of patch cords stackable 4 mm spring loaded plug length ½ meter.*Good Quality, reliable terminal/sockets are provided at appropriate places on panel for connections  & observation.
