X-Ray Diffractometer India

X-Ray Diffractometer Supplier and Exporter – Designed for research laboratories, universities, material science, metallurgy, geology, ceramics, pharmaceuticals, and industrial quality control, this X-Ray Diffractometer (XRD) provides precise phase identification, crystal structure analysis, and material characterization. The system combines advanced optics, a high-precision goniometer, and sensitive detection technology to deliver reliable diffraction data for research and analytical applications.

Technical Specifications:

• X-ray generator power: 600 W

• Tube voltage: 40 kV

• Tube current: 15 mA

• Rotary shutter linked with safety interlock

• X-ray tube options: Cu, Co, Fe, or Cr

Optics:

• Divergence slit: Fixed or variable

• Scattering slit: Fixed

• Receiving slit: Fixed

• Kβ foil filter

• Graphite monochromator

• Soller slit: 5.0° or 2.5°

Goniometer:

• Vertical configuration

• Radius: 150 mm

• Scanning range: -3° to 145° (2θ)

• Scanning speed: 0.01–100°/min (2θ)

• Minimum step width: 0.005° (2θ)

• Angular accuracy: ±0.02°

Detector:

• NaI scintillation counter

• Optional D/teX Ultra high-speed silicon strip detector

Power Supply:

• Main unit: 220/240 V AC, Single Phase, ±10%

• PC: 220/240 V AC, Single Phase, ±10%

Accessories:

• Computer (PC) interface

• Instrument control and data acquisition software
