DC Dynamometer For Motor Testing (Electrical Lab)

DC Dynamometer For Motor Testing (Electrical Lab)

Product Supply Code: ADM-012-NE

Details for DC Dynamometer For Motor Testing (Electrical Lab)

DC Dynamometer For Motor Testing for Electric Motors Teaching Labs  (Electrical Lab) - This Model is an educational model suitable for demonstrating to students the complete know of the Basics, Components, Mechanicals, Loading methods, Torque evaluation, Loading scheme, Wear & Tear & Maintenance of these motors packaged in small rating. Students can make connections of their own with the help of the terminations provided for study of features viz Coupling the motor to be tested, Starting methods, Speed-Torque, Excitation control of Dynamometer, Power dissipation of Generator, Torque measurement. Technical Specs : Power ratings available : 1KW / 2KW/ 5KW/ 10KW Voltage Input: 230V DC RPM: 1440 / 2880 RPM Single / Double shaft extension, SPDP, IP23, IC01, B3, Class-B, S1, Solid yoke List Of Experiments : Load testing of AC Motor Load testing of DC Motor Torque calculation at various rpm Speed-Torque Analysis Voltage-Speed Analysis Speed reversal Efficiency Analysis Blocked rotor test Cold Resistance & Hot Resistance Motor Operation parameters Basic Overhauling Know how.
