EDDY Current Dynamometer for Motor Testing for Electrical Lab

EDDY Current Dynamometer for Motor Testing for Electrical Lab

Product Supply Code: ADM-013-NE

Details for EDDY Current Dynamometer for Motor Testing for Electrical Lab

EDDY Current Dynamometer for Motor Testing for Electric Motors Teaching Labs  for Electrical Lab - This Model is an educational model suitable for demonstrating to students the complete know of the Basics,Components, Mechanicals, Loading methods, Torque evaluation, Loading scheme, Wear & Tear & Maintenance of these motors packaged in small rating. Students can make connections of their own with the help of the terminations provided for study of features viz Coupling the motor to be tested, Starting methods, Speed-Torque, Excitation control of Dynamometer, Torque measurement. (Providing Load cells is an option) Technical Specs : Power ratings available : 1KW / 2KW/ 5KW/ 10KW Voltage Input: 230V AC to Exciter unit Rpm of Machine 1500 Single shaft extension, SPDP, IP23, IC01, B3, Class-B, S1, Solid yoke List Of Experiments: Load testing of D Load testing of AC Motor C Motor Torque calculation at various rpm Speed-Torque Analysis Voltage-Speed Analysis Speed reversal Efficiency Analysis Blocked rotor test Cold Resistance & Hot Resistance Motor Operation parameters Basic Overhauling Know how.
