Farm Tractor Cutaway Trainer 4-Stroke 4-Cylinder Diesel Engine

The Farm Tractor Cutaway Trainer – 4-Stroke 4-Cylinder Diesel Engine is a premium educational training model designed to demonstrate the internal construction, operating principles, and maintenance of a modern agricultural tractor. The trainer has been precision sectioned to expose major engine and transmission components, providing students with a clear understanding of mechanical systems through safe, hands-on observation.

Each cutaway component has been professionally finished using contrasting colors to distinguish internal assemblies, lubrication passages, and cross-sectional areas, making identification of individual parts simple and effective. Selected components are chrome-plated and galvanized to enhance durability and provide excellent corrosion resistance for long-term laboratory use.

The trainer is electrically driven by a 230 V AC motor, allowing all moving components to operate safely at a reduced speed. This enables learners to clearly observe the movement of pistons, crankshaft, valve train, gearbox, steering components, and other mechanical systems without the hazards associated with a running engine.

Mounted on a robust steel frame fitted with heavy-duty wheels, the trainer is easy to transport and ideal for engineering colleges, technical institutes, agricultural machinery training centres, and vocational education laboratories.

Key Features

• Fully operational cutaway tractor training model

• Precision sectioned engine and transmission assemblies

• Professionally color-coded internal components

• Electrically driven for safe classroom demonstrations

• Reduced operating speed for clear visualization of moving parts

• Chrome-plated and galvanized components for long service life

• Heavy-duty mobile steel stand with industrial wheels

• Ideal for maintenance training, technical education, and workshop demonstrations

Technical Specifications

• Engine Type: 4-Stroke, 4-Cylinder Diesel Engine

• Engine Displacement: 2,000 cc

• Fuel Injection System: Indirect Injection

• Cooling System: Water Cooled

• Valve Mechanism: Overhead Valves (OHV)

• Fuel Pump: In-Line Fuel Injection Pump

• Steering System: Globe-Type Steering Gearbox

• Transmission: 4 Forward Speeds + 1 Reverse Gear

• Operation: Electrically Driven

• Power Supply: 230 V AC

• Mounting: Heavy-Duty Steel Stand with Wheels

Educational Experiments

• Four-stroke diesel engine operation

• Internal combustion engine component identification

• Fuel injection system demonstration

• Valve timing and valve train operation

• Cooling and lubrication system study

• Gearbox and transmission mechanism analysis

• Steering system operation

• Power transmission through the drivetrain

• Preventive maintenance procedures

• Engine servicing and inspection techniques

Applications

• Agricultural Machinery Training

• Tractor Maintenance and Repair Education

• Mechanical Engineering Laboratories

• Automotive Engineering Training

• Technical and Vocational Education

• Industrial Skills Development

• Farm Equipment Service Training

• Research and Demonstration Laboratories

Industries Served

• Agricultural Engineering Colleges

• Engineering Universities

• Technical Training Institutes

• Vocational Education Centres

• Automotive Training Schools

• Agricultural Machinery Manufacturers

• Farm Equipment Service Centres

• Industrial Training Facilities

• Research and Development Laboratories
