Reynold s Apparatus Manufacturer, Supplier and Exporter

Reynold s Apparatus

Product Code: FML0001

Details for Reynold s Apparatus

Reynold s Apparatus.
The Set-up is designed to verify Reynold's Apparatus experimentally. The Apparatus consists of a glass tube which one end having bell mouth entrance connected to a water tank. At the other end of the glass tube a cock is provided to vary the rate of flow. Flow rate of water can be measured with the help of Measuring Cylinder and Stop Watch, supplied with the set-up. A capillary tube is introduced centrally in the bell mouth. To this tube dye is fed from a small container, placed at the top of Constant head Tank, through polythene tubing.

EXPERIMENTS:-

  • To study different types of flow.
  • To determine the Reynold's Number and hence the type of floe either laminar or turbulent.

UTILITIES REQUIRED: - Water Supply. Drain.

TECHNICAL SPECIFICATION: -
Tube : Material Borosilicate Glass Dye Vessel : Material SS, Suitable Capacity Capillary Tube : Material Copper/Stainless Steel Constant Head Water Tank : Capacity 40 Liters. Water Circulation : FHP Pump Flow Measurement : Using Measuring Cylinder Sump Tank : Capacity 60 Liters. Stop Watch : Capacity 60 Liters. Electronic Control Panel Comprises of : Standard make, On/Off Switch, Mains Indicator, etc. The Whole set-up is well designed and arranged in a good quality painted structure, Civil Engineering  Laboratory  Equipments Suppliers, Mechanical Engineering Laboratory Equipments Suppliers
, Engineering Teaching Aids, Models Equipments Theory of Machine Lab  Suppliers, Hydraulics Laboratory Equipment and Apparatus

We are leading manufacturers, suppliers & exporters of Reynold s Apparatus. Contact us to get high quality designed Reynold s Apparatus for schools, colleges, universities, research labs, laboratories and various industries. We accept bulk orders for government tenders in all countries around the globe.

For similar products visit at main page of Fluid Mechanics Laboratory Instruments.
