REYNOLDS APPARATUS for engineering schools

REYNOLDS APPARATUS for engineering schools

Product Supply Code: MCH0010

Details for REYNOLDS APPARATUS for engineering schools

REYNOLDS APPARATUS for engineering schools.
REYNOLDS APPARATUS, technical teaching equipment for engineering -Reynolds's Number is a dimension less number used by engineers to determine type of Fluid Flow and testing on scale down models of airplanes, ships etc.     Apparatus consists of a constant head tank and a small ‘dye’ tank. The constant head tank has a horizontal/verticaltransparent tube with a and a flow control valve at the dischargeside. The velocity of water is varied by the flow control valve.When the dye is introduced then laminar or turbulent nature of the flow can be visualized.      Sump Tank : 550 X 430 X 225.     Flow Pipe length: 700 mm.     Measuring Flask: 1 litre.     Dye Material : Potassium Permangante.     Pump : Submersible type.     Piping with necessary Valves and Fittings.     Digital Stop Watch with 1/10 second Accuracy.     Detailed Technical Manual and On-site demo.
