Single Phase AC Induction Motor

Single Phase AC Induction Motor

Product Supply Code: ADM-005-NE

Details for Single Phase AC Induction Motor

 for Electric Motors Teaching Labs 1Ph AC Squirrel Induction Motor Cap. Start for Electrical Lab - This Model is the Industrial/Educational model suitable for demonstrating to students the complete know of the Basics, Components, Starting methods, Wear & Tear & Maintenance of these motors packaged in small rating. Students can make connections of their own with the help of the terminations provided for study of features viz Starting methods, Speed-Torque, Effect of Phase angle, Study of Cogging/Crawling, Effect of reduced voltage, Blocked rotor test. 1Ph AC Squirrel Induction Motor Cap. Start Technical Specs : Power ratings available : 350W / 750W / 1KW / 1.5KW Voltage Input: 230V AC 50hz RPM: 1440 / 2880 RPM Single / Double shaft extension, TEFC, IP44, IC01, B3, Class-B, S1, Casting/Sheet metal body 1Ph AC Squirrel Induction Motor Cap. Start List of Experiments Starting by DOL Starter Starting by reduced voltage starter. Load test & No load test of machine Speed-Torque Analysis Voltage-Speed Analysis Speed reversal Efficiency Analysis Blocked rotor test Cold Resistance & Hot Resistance Motor Operation parameters Basic Overhauling Know how.
