Communication & RF Trainers

Communication & RF Trainers
Communication & RF Trainers

DSB/SSB AM Transmitter Trainer for Communication Teaching Labs

LAB CODE: COM-TR-01

DSB/SSB AM Transmitter Trainer DSB/SSB AM Transmitter Trainer - Internal 300Hz to 3.4KHz Sinewave
generator. 2 Nos. of balanced modulator with band pass filter (1MHz)
& 1 No. of balanced modulator (455KHz). Ceramic band pass filter,
Carrier Frequency of 1MHz. Audio output amplifier with speaker. compact
and user friendly learning platforms to provide a modern, portable, ...

DSB/SSB AM Receiver Trainer for Communication Teaching Labs

LAB CODE: COM-TR-02

DSB/SSB AM Receiver Trainer - DSB/SSB AM Receiver Trainer Frequency range of 525 to 1625Khz. Receiver
CKT consist of RF amplifier, mixer, local oscillator, BFO, IF
amplifier-1, IF amplifier-2. Diode detector for DSB & Product
detector for SSB. Audio output amplifier with Speaker. compact and user
friendly learning platforms to provide a modern, portable, comprehensive
and ...

FM Transmitter Receiver Trainer for Communication Teaching Labs

LAB CODE: COM-TR-03

FM Transmitter Receiver Trainer - FM Transmiter Receiver Kit - FM Transmitter Receiver Trainer: Internal
300Hz to 3.4KHz sinewave generator. FM Modulation using reactance
Modulator & Varactor Modulator. Transmitter Frequency to 455 KHz. FM
Demodulator using detuned Resonant detector, Quadrature detector.
Fooster seeley detector, Ratio detector & PLL detector. Low Pass
filter ...

FM Communication Trainer for Communication Teaching Labs

LAB CODE: COM-TR-04

FM Communication Trainer - FM Communication Trainer - Study of FM Communication is a comprehensive
learning solution specifically designed to provide conceptual and step
by step understanding of Frequency Modulation and Demodulation
techniques through observation of waveforms at various test points and
measurement of parameters like Frequency deviation and Modulation index.
Block wise ...

Noise Audio-Amplifier Trainer for Communication Teaching Labs

LAB CODE: COM-TR-05

Noise Audio-Amplifier Trainer - Noise Audio-Amplifier Trainer communication system which specifies basic
concepts of noise generation & its amplification. Noise &
signal adder where noise is added to signal and its amplitude is
adjusted from 0 to max of I/P value. It consists of an audio amplifier
section in which signal +noise can be amplified and its effects can be
examined ...

Four channel Analog TDM Trainer for Communication Teaching Labs

LAB CODE: COM-TR-06

Four channel Analog TDM Trainer - Four channel Analog TDM Trainer -Four channel analog TDM Trainer
demonstrate Time division multiplexing technique. The platform provides
all necessary inputs and connections for students to study amplitude
modulation, demodulation, multiplexing and demultiplexing techniques.
The platform is student friendly & completely self contained, having
all ...

Frequency Division Multiplexing/ Demultiplexing Trainer for Communication Teaching Labs

LAB CODE: COM-TR-07

Frequency Division Multiplexing/ Demultiplexing Trainer - Frequency Division Multiplexing/ Demultiplexing Trainer - Frequency
Division MUX-DEMUX- Trainer :compact and user friendly learning
platforms to provide a modern, portable, comprehensive and practical way
to learn Technology. Each TechBook is provided with detailed Multimedia
learning material which covers basic theory, step by ...

TDM Pulse Amplitude Modulation /Demodulation Trainer for Communication Teaching Labs

LAB CODE: COM-TR-09

TDM Pulse Amplitude Modulation /Demodulation Trainer -

TDM Pulse Code Modulation Transmitter Trainer for Communication Teaching Labs

LAB CODE: COM-TR-10

TDM Pulse Code Modulation Transmitter Trainer -

TDM Pulse Code Modulation Receiver Trainer for Communication Teaching Labs

LAB CODE: COM-TR-11

TDM Pulse Code Modulation Receiver Trainer - TDM Pulse Code Modulation Receiver Trainer - Features

Input accepts two channel multiplexed data

On board De-multiplexed PCM Receiver

On board L. P. Filter

Fast & Slow modes for real time operation and data flow examination

On board PLL for clock regeneration

On board sync code detector

Error ...

Delta, Adaptive Delta and Delta Sigma Modulation/ Demodulation Trainer for Communication Teaching Labs

LAB CODE: COM-TR-12

Delta, Adaptive Delta and Delta Sigma Modulation/ Demodulation Trainer -

Data Formatting and Carrier Modulation Transmitter for Communication Teaching Labs

LAB CODE: COM-TR-13

Data Formatting and Carrier Modulation Transmitter - Data Formatting and Carrier Modulation Transmitter - compact and user
friendly learning platforms to provide a modern, portable, comprehensive
and practical way to learn Technology. Each TechBook is provided with
detailed Multimedia learning material which covers basic theory, step by
step procedure to conduct the experiment and other ...

Carrier Demodulation and Data Reformatting Receiver for Communication Teaching Labs

LAB CODE: COM-TR-14

Carrier Demodulation and Data Reformatting Receiver - Carrier Demodulation and Data Reformatting Receiver - compact and user
friendly learning platforms to provide a modern, portable, comprehensive
and practical way to learn Technology. Each TechBook is provided with
detailed Multimedia learning material which covers basic theory, step by
step procedure to conduct the experiment and ...

Audio Input Trainer Module for Communication Teaching Labs

LAB CODE: COM-TR-15

Audio Input Module - Audio Input Module -The module accepts an audio input signal. The
built-in power amplifier output drives an 2.5 inch speaker providing the
audio output. A volume control is provided to adjust the volume.
Headphone Socket can be used to connect headphones. The input may come
from Receiver Trainer.

Converts audio frequency electric signals to audible output.<br ...

Audio Output Trainer Module for Communication Teaching Labs

LAB CODE: COM-TR-16

Audio Output Module - Audio Output Module The module accepts an audio input signal. The
built-in power amplifier output drives an 2.5 inch speaker providing the
audio output. A volume control is provided to adjust the volume.
Headphone Socket can be used to connect headphones. The input may come
from Receiver Trainer.

Converts audio frequency electric signals to audible ...

PAM-PPM-PWM Modulation & Demodulation Trainer for Communication Teaching Labs

LAB CODE: COM-TR-17


PAM-PPM-PWM Modulation & Demodulation Trainer -compact and user
friendly learning platforms to provide a modern, portable, comprehensive
and practical way to learn Technology. Each TechBook is provided with
detailed Multimedia learning material which covers basic theory, step by
step procedure to conduct the experiment and other useful information.
PAM-PPM-PWM are the basic ...

Digital Communication Training System for Communication Teaching Labs

LAB CODE: COM-TR-23

Digital Communication Training System - Digital Communication Training System -compact and user friendly
learning platforms to provide a modern, portable, comprehensive and
practical way to learn Technology. Each TechBook is provided with
detailed Multimedia learning material which covers basic theory, step by
step procedure to conduct the experiment and other useful information.
In ...

16 QAM Training System for Communication Teaching Labs

LAB CODE: COM-TR-25

16 QAM Training System - 16 QAM Training System -Today advanced communication technologies are
growing in a tremendous way. Technologies like wireless communication,
mobile communication, satellite communication, data communication, RF ID
etc enters in our daily lives. M-ary signaling schemes are preferred
over binary signaling schemes for transmitting digital information over ...

Differential Pulse Code Modulation (DPCM) Trainer for Communication Teaching Labs

LAB CODE: COM-TR-26

Differential Pulse Code Modulation (DPCM) Trainer -

PN Sequence Generator Trainer for Communication Teaching Labs

LAB CODE: COM-TR-27

PN Sequence Generator - PN Sequence Generator -PN Sequence Generator demonstrates the basic
scheme used to transmit an information signal. It covers very basic
concepts like how to generate the PN sequence which can be used to send
data in a secure manner. Output port provides the facility to observe
the output signals in terms of pulses which is nothing but the PN
sequence for ...

MSK Modulation / Demodulation Trainer for Communication Teaching Labs

LAB CODE: COM-TR-28

MSK Modulation / Demodulation Trainer - MSK Modulation / Demodulation Trainer -demonstrates the basic working of
Minimum Shift Keying technique. As the name suggests, MSK results in a
modulation scheme which has smooth phase variations in contrast to other
phase modulation schemes where the modulated signal contains abrupt
phase changes. The immediate advantage of such a scheme is the ...

Error Detection and Correction-Cyclic Code Trainer for Communication Teaching Labs

LAB CODE: COM-TR-29

Error Detection and Correction-Cyclic Code Trainer - friendly learning platforms to provide a modern, portable, comprehensive
and practical way to learn Technology. Each TechBook is provided with
detailed Multimedia learning material which covers basic theory, step by
step procedure to conduct the experiment and other useful information.
Error Detection and Correction - Cyclic Code ...

PCM Generation & Demodulation using CODEC Chip Trainer for Communication Teaching Labs

LAB CODE: COM-TR-30

PCM Generation & Demodulation using CODEC Chip - PCM Generation & Demodulation using CODEC Chip -compact and user
friendly learning platforms to provide a modern, portable, comprehensive
and practical way to learn Technology. Each TechBook is provided with
detailed Multimedia learning material which covers basic theory, step by
step procedure to conduct the experiment and other ...

Mobile Phone Trainer for Communication Teaching Labs

LAB CODE: COM-TR-31

Mobile Phone Trainer - Real time mobile operation
Expanded and open TechBook
Full explaination of mobile phone working
Frequency measurement and band verification
Provides study of all sections in mobile phone
TX/RX Frequency measurement
2G technology & GMSK signals
GSM data rate
Detail study of User Interface Control signals
Detail study of SIM operation
Battery identification ...

GSM Application Module Trainer for Communication Teaching Labs

LAB CODE: COM-TR-33

GSM Application Module - GSM Application Module -GSM has achieved total global acceptance for its
voice & data service. Further, capabilities of GSM/GPRS for
supporting applications make it unique. What are AT commands ? What can I
do with them ? I` m unable to make out the response of AT commands ?
Scientech Technologies presents Scientech2133AM GSM application module a
solution ...

Global Positioning System - GPS Trainer for Communication Teaching Labs

LAB CODE: COM-TR-34

GPS Trainer - Global Positioning System Trainer

CDMA-Direct Sequence Spread Spectrum (DSSS) Trainer for Communication Teaching Labs

LAB CODE: COM-TR-37

CDMA-Direct Sequence Spread Spectrum (DSSS) Trainer -

2 Channel CDMA - Direct Sequence Spread Spectrum Training System for Communication Teaching Labs

LAB CODE: COM-TR-38

2 Channel CDMA - Direct Sequence Spread Spectrum Training System -

Understanding Local Area Network (LAN) Trainer for Communication Teaching Labs

LAB CODE: COM-TR-42

Understanding Local Area Network (LAN) Trainer -

Antenna Trainer for Communication Teaching Labs

LAB CODE: COM-TR-44

Antenna Trainer -  Antenna Trainer - The desktop Antenna Training System has been
specially designed for engineering colleges and training centers. It is
very useful for introducing practical verification of antenna operation
to the students. The work book provides theoretical concepts and detail
procedure of experiments with each type of antenna. The training system
includes ...

Motorised Antenna Unit for Communication Teaching Labs

LAB CODE: COM-TR-45


Antenna Trainer (Motorized) - Motorised Antenna Unit: Microconroller Based High Precision DC Stepper Motor, Automatic Zero Point setting, uilt-in DC Power Supply, Instant Plotting of radiation Pattern, Resolution: 1°
Technical Specifications:
RF Input
Detector: Active with 5 pin DIN Connector
Antenna Rotation: 360° (1° Resolution)
Power Supply: 220/110 V, 50 Hz / 60 Hz ...

Microstrip Antenna for Communication Teaching Labs

LAB CODE: COM-TR-47

Microstrip Antenna Microstrip Antenna -PLL Synthesized Transmitter & Receiver

100 Memories

Alpha Numeric LCD Display With Backlit

Experiments on Microstrip/ Patch and other types of Antennas

Gunn Power Supply for Communication Teaching Labs

LAB CODE: COM-TR-49

Gunn Power Supply - Gunn Power Supply Gunn Power Supply is a Microcontroller based Equipment
with LCD. A very important feature of this instrument is the
simultaneous display of Voltage and Current which is the basic and
necessary requirement of V-I Characteristics experiment. Here different
Modulation Modes are single switch selectable with display on LCD. For
PC to PC Data ...
