Hand Microtome: Biology Science Lab Microscope Accessories - Brass top plate 6.5 cm. dia. with centered hole 2.3 cm. dia. Overall length 8.5 cm. The milled head at the base when revolved records 20 microns per click, for section cutting.
Hand and Table Microtome - Microtomes Biology Stage dia. 80mm. vertical lift 20 mm. and least count 0.01 mm, Can be securely attached to the edge of bench, table or work surface with the help of fixing clamp.
Hand Microtome External Milled Knob with a micrometer scale of 50 divisions of 10 microns. Maximum sample section of 20 mm. Minimum cut of 10 microns. Complete in case.
Microtome (Ranvier type) - Ranvier's Microtome is simply a smaller instrument; the whole apparatus can be inverted in spirit, if it be desired to make sections of the same tissue from time to time.
Rotary Microtome - Heavy base with hinged cover for protecting the interior mechanism, and knife holder. With every complete revolution of the drive wheel, the feed panel engaged the teeth of ratchet wheel which advances the object holder through cone and inclined plane mechanism. A safety device automatically disengages the feed mechanism. Feed indicator is in front and fed setting is at back ...
For collection of botanical specifications from field. Made of 22 SWG aluminum sheet. Handle and adjustable holder strap provided for easy handling. Exterior well painted and interior provided with 2 mm. cork sheet.
For pinning of insects both top & bottom insides. Teakwood frame with sunmica top & plywood bottom is finished in lacquer polish. Top & bottom lined with 8 mm thick EVA sheet. Inside glazed white with art papper. Raised wooden wall with holes for insecticide, inside bottom to make box air- tight and pest proof. Fitted with brass hinges, index card holder and clips.
Wooden, covered with non scaring, synthetic sheet suitable for repeated pinning without leaving pin marks. Groove smoothly adjustable in width for various sizes of insects up 12 mm.
Ring made of iron wire supported on anodized aluminum pipe handle with fine rubber grip at end. Length of handle 75 cm. fitted in ring through 5 cm. wide cloth rim. dia. to bag at free end 25 cm. Ring dia. 30 cm.
1. Insect Collecting Net with Aluminium Handle
2. Insect Collecting Net with Wooden Handle
Designed specially for collecting animals and vegetation from ponds or stream bottom. Sturdy metal edge net has strong cloth backed with metal wire mesh. Strong top ring has flattened outer edge to facilitate bottom sampling. Net collapse completely for carrying and storage. Includes removable, aluminium extension handle.
35” long collection bag made of strong bolting netting cloth suspended by muslin reinforcement and mounted on a strong wire ring dia. 12”. Three braided strong leads attached to swivel front. Lower end is provided with 2” opening with strong cloth pocket for tying the collection vial.
Strongly built for sweeping up of aquatic fauna and useful as a general utility aquatic net. Net ring and handle can be separated for easy carriage. Strong ‘D’ shaped ring frame dia. 12” with stout handle.
Stainless steel, consisting of 20 instruments for accurate dissection. Supplied in canvas case.
Scissors 2 Nos.
Forceps 2 Nos.
Needles 4 Nos.
Scalpel 1 No.
B.P. Handle with Blade 1 No.
Razor 1 No.
Watch Glass 1 No.
Magnifying Glass 1 No.
Glass Slide 1 No.
Chain and Hook 1 No.
Cover Slips. 1 No.
Ideal for laboratory and field use, this apparatus allows the student to measure transpiration with minimal risk of breakages. The apparatus has only one glass component (the capillary tube) and is mounted on a strong backing plate. It consists of a capillary tube with millimeter scale connected via. 3 -way tap to a syringe. The cut shoot is connected to the third outlet. The apparatus can ...
For demonstration of transpiration rates and rates of water absorption by a cut shoot under various external conditions. A plant shoot is sealed into a stopper which fits the end tube and the whole apparatus is filled with water, the open end of the capillary tube, which is graduated in millimeter, dipping into beaker of water.
Suitable for individual student use, the cut shoot is attached to the side arm with tubing and the wide glass tube acts as the reservoir. Glass tube 160 x 20 mm., with side arm 8 mm. diameter. Capillary tube length 140 mm. with 1 mm. Bore.
For measuring the rate of uptake of water by a cut plant shoot. The apparatus consists of a central reservoir with a three whole stopper holding a capillary tube graduated in millimeters, a funnel with stopcock and a short length of 10 mm glass tubing, to hold the plant shoot.
Designed for demonstration of osmotic pressure at an elementary level in biology. A semi-permeable is attached to the wide end of a funnel having an indicator tube. The funnel is fixed in the reservoir, supplied with teat dropper pipette.
A complete unit, for comprising rates of absorption or revolution of gases by small organisms, during respiration, the apparatus consists of two boiling tube with stoppers connected by three way taps to either limb of a graduated manometer. One tube holds the organism and has a syringe for altering the level of liquid in the manometer during setting up.
For clinostat in place of the cork disc. A cylindrical aluminium vessel, 87 mm. and 100 mm. high. Holder accommodates any size or shape of pot up to 75 mm. dia.
For demonstration of heliotropism and geotropism. Germinating seedlings are pinned to the cork table which is rotated by an electric motor at 4 revolutions per hour. The motor is spindle mounted and may be clamped by a thumbscrew so that the place of the table can be set at any angle between horizontal and vertical.
