Electronics Lab Experiments

Physics Lab Diode Unit Silicon semiconductor diodes, electronic components manufacturer exporter. Variable Capacitors variable capacitance model Triode Valve Mounted, Vacuum tube solar cell unit, solar power kits, solar powered fan kit laboratory , dual output power supply, variable power supplies, adjustable power supply, ac dc converter, portable power supply, custom power supplies, ac dc power supply manufacturers, Photo Electric Cell Unit, Miniature, Mini DC Solar Motor for science study kits and experiments Fixed capacitors have fixed capacitance value, Diode Unit Silicon Semi conductor diodes internal potential is 0.7V, germanium 0.3V, schottky 0.2V, Zener Diode Unit, Silicon Diode unit, Thermistor Unit, N-P-N Transistor Unit, , P-N-P Transistor Unit, Light Dependent Resistor, diode valve mounted unit

Oscilloscope Dual Trace 20 MHz for Physics Lab

PECS-0001

Elegant, DC to 20MHz Bandwidth 1mV/div Sensitivity on Both Channels CH1 & CH2 Independent Channels CH1 or CH2 Trigger Signal Output Algebraic Addition and Subtraction X-Y Operation 10ns/div to 0.2s/div Time Base Z Modulation TTL Level 8 x 10 cm Display Internal Graticule TV Triggering Frame (V) & Line (H) Line Trigger, ALT Triggering, Trigger Lock Facility, Single Sweep, Variable....

Oscilloscope Single Trace 10 MHz for Physics Lab

PECS-0002

DC to 10MHz Bandwidth, 5mV/div Sensitivity, 100ms/div to 100ns/div Time Base, X-Y Operation, Auto or Normal Trigger Selection, Triggering upto 15MHz, 8 x 10 cm Display, Trace Rotation, 140mm Rectangular CRT, Internal Graticule
Space Saver

Power Supply (D.C) Regulated (Digital) 0-30V: Capacity: 1A for Physics Lab

PECS-0003

The DC Regulated Power Supply is an easy to use, low ripple high regulation precision instrument. Its unique feature is overload protection which makes it a safe power source for testing of electronic equipment.

Power Supply (D.C) Regulated (Digital) 0-30V: Capacity: 2A for Physics Lab

PECS-0004

The DC Regulated Power Supply is an easy to use, low ripple high regulation precision instrument. Its unique feature is overload protection which makes it a safe power source for testing of electronic equipment.

Power Supply (D.C) Regulated (Digital) 0-30V: Capacity: 5A for Physics Lab

PECS-0005

The DC Regulated Power Supply is an easy to use, low ripple high regulation precision instrument. Its unique feature is overload protection which makes it a safe power source for testing of electronic equipment.

Power Supply (D.C) Regulated (Digital) 0-30V: Capacity: 10A for Physics Lab

PECS-0006

Power Supply 5 KV E.T.H. for Physics Lab

PECS-0007

Output 100 to 5 KV at 3 mA continuous. Fully floating EHT circuits suitable for operation of spart, counters, discharge tubes etc. Provided variable output upto 5 KV. The EHT circuit are fully floating so that certain experiments the positive or negative terminals may be safely connected to earth.

Power Supply A.C/D.C Low Tention for Physics Lab

PECS-0008

0-20 volts D.C. And 0-25 volts A.C. continuously variable at 10/5/2 Amps. With dual meter to read volts AC/DC.

Power Supply AC/DC Low Voltage with Display Meter for Physics Lab

PECS-0010

With Digital or analogue display meters, 2 to 12 volts in step of 2 volts.

Cathode-Ray Tube Deflection Effect for Physics Lab

PECS-0011

Deflection Effect : to demonstrate the deviation of cathode ray by means of a magnet.

Cathode-Ray Tube Shadow Effect for Physics Lab

PECS-0012

Shadow Effect: with cross of aluminium jointed to show the cathode ray going downward revealing a shadow of the cross at the back when discharged.

Helmholtz Coils for Physics Lab

PECS-0013

Provide a substantially uniform field at the centre space. Each coil has a moulded plastic former 152 mm in diameter with 320 turns of 22 SWG, enamelled wire giving a mean diameter of 136 mm.

MultiVolt Transformer A.C. for Physics Lab

PECS-0014

Voltage output 1, 2, 3, 4, 5, 6, 7, 8, 9, 10 and 12 V A.C. selectable from 2, 4, 6, 8, 12 volts tappings. Current output 6A continuous, 8A maximum upto 1 hour.

Ohms Law Apparatus for Physics Lab

PECS-0015

This apparatus is designed to demonstrate Ohms Law. Consisting of a sheet metal enclosure with milliammeter, voltmeter, rheostat, push key and terminal posts.
